welder and generator,powered by air cooled diesel engine,1 cylinder

4

It is a 2kw generator,at the same time,it is a welder with 160A-180A.

powered by air cooled diesel engine.

Electric start by battery,or manual start.

with 4 wheels for easy portable,8hours fuel tank.

You can make welding work even where has not stable electricity.

  Model
5GF-MEW
6GF-MEW
Welder Rated kva
2
2.2
Rated Cuttent(A)
50-160A
50-180A
Rated Coltage(V)
26
Aplicable Electrode(mm)
2.6-3.2
Ac generator Rated Output
2
Rated Frepuency
50
Rated Voltage
220
Engine(diesel) Model
YM186FG
YM186FAG
Type
Single-cylinder,vertical 4-strode,Air-cooled
Set Dimension(mm)
770x500x630
770x500x630
Dry Weight (kg)
98
98

Welder and generator,powered by water cooled diesel engine,multi- cylinder

model
DW200A
DW250A
DW300A
DW400A
DW450A
DW550A
Max current(A)
200
250
300
400
450
550
generator output
3kw
3kw
3kw
3kw
5kw
8kw
empty load voltage(V)
60-70
60-70
60-70
60-70
60-70
60-70
rated voltage(V)
36
36
40
40
40
40
electrode diameter
2-4mm
2-8mm
engine model
Y385D
Y480D
YND485D
YSD490D
Y495D
Y4102D
engine brand
Yangdong
Yangdong
Yangdong
Yangdong
Yangdong
Yangdong
cooling type
water
water
water
water
water
water
engine rated output
11KW
14KW
17KW
21KW
27KW
33KW
rpm
1500
1500
1500
1500
1500
1500
cylinder number
3
4
4
4
4
4
fuel consupmtion(L/H)
2.3
3
3.5
4.5
5.1
6.8
start method
electric
electric
electric
electric
electric
electric
protection class
IP23
IP23
IP23
IP23
IP23
IP23
noise level
65-70db
65-70db
65-70db
65-70db
65-70db
65-70db
structure
base frame type or  trailer type
L(m)
1.55
1.55
1.75
1.75
2
2.3
W(m)
0.7
0.7
0.75
0.75
0.85
0.85
H(m)
0.95
0.95
1.1
1.1
1.1
1.1
net weight(kg)
650
700
750
800
850
900

Together with welder,we also supply AWS E6013/E7018 electrodes with diameter 2.5x300mm , 3.2x350mm, 4x400mm.

Lanthanated Tungsten electrode 1.6mm-4mm,added 1.5% La2O3.




 passion to win!

  contact:Tel:0086-21-51345192 Fax:0086-21-51345190 Email: wolfshen@yy-md.com
